jQuery, JSON, and ASMX 2.0 Services

A few weeks ago, I had a project that was grounded in the .Net Framework v2.0 and Visual Studio 2005.  The requirements were very focused on usability and speed so AJAX and jQuery were high on my list to use.  Through the project, I learned that there isn't a large amount of information in one place that tells you how to setup a ASP.Net solution that uses jQuery and ASMX services to effectively transmit json data back and forth from the client.  Because of this, I'll attempt to fill this void since there are still many developers and companies out there that have not been able to upgrade to Visual Studio 2008.

In this post, I'll discuss the process of building a plain ASP.Net 2.0 web application project (not web site project) , setting up the necessary entries in the web.config file to utilize the ASP.Net 2.0 AJAX Extensions v1.0, and use jQuery at the client side of the transfers.    In addition, I'll also show to to use the JavaScriptSerializer class and how to write your own custom converter for your objects.


A Note About This Post:

This post is focused on Visual Studio 2005 with the ASP.Net 2.0 AJAX Extensions v1.0.  The v3.5 of the extensions that came with ASP.Net v3.5 and Visual Studio 2008 have a few changes.  While I will try to point out the differences, the core of this post is going to be focused on Visual Studio 2005 web application projects and v1.0 of the AJAX extensions.  While we all love focusing on the latest and greatest, I'm aware that there are a large number of companies and professionals out there that are locked into using the older version of the software for a number of reasons.


Additions to VS2005 Used in This Post:

This post will be using the following additions to VS2005.  Below are the items and links to their respective installers:


Code Downloads for This Post:


Creating and Configuring a New WAP:

Now that we have the required additions established, we're ready to create a new ASP.Net 2.0 Web Application Project.  I'm not going to get into the details of how to do this; however, I want to stress that I'm NOT choosing an ASP.Net AJAX Enabled Web Application.  I'm just choosing to create a new, basic ASP.Net Web Application Project.  Now that the project has been created, we need to add a few references and add some information into the Web.Config file.

In the Solution Explorer, we'll need to add a reference to the AJAX Extensions v1.0 library, System.Web.Extensions.dll.  By default, this library is located at C:\Program Files\Microsoft ASP.Net\ASP.Net 2.0 AJAX Extensions\v1.0.61025\ directory.  After adding this reference, we can update our Web.Config file by including a reference to the ScriptHandlerFactory HttpHandler using the following snippet inside of the <System.Web> config section:

   1: <remove verb="*" path="*.asmx"/>
   2: <add verb="*"
   3:      path="*.asmx"
   4:      validate="false"
   5:      type="System.Web.Script.Services.ScriptHandlerFactory,
   6:            System.Web.Extensions,
   7:            Version=1.0.61025.0,
   8:            Culture=neutral,
   9:            PublicKeyToken=31bf3856ad364e35"/>

By adding the AJAX Extensions reference and updating the web.config file, we're now ready to enable our ASP.Net Web Services (ASMX) to be called from JavaScript.


Setting Up an ASMX Web Service:

We have our new WAP setup and configured, it's time to write a simple ASMX web service and configure it so that it will be able to return JSON.  To do this, let's add a web service to our project called JsonService.asmx and add the following code snippet to replace some of the defaults Visual Studio gives you:

   1: using System.Collections.Generic;
   2: using System.Web.Script.Services;
   3: using System.Web.Script.Serialization;
   5: [WebService(Namespace = "")]
   6: [WebServiceBinding(ConformsTo = WsiProfiles.BasicProfile1_1)]
   7: [ScriptService()]
   8: public class JsonService : System.Web.Services.WebService
   9: {
  10:     [WebMethod]
  11:     [ScriptMethod(ResponseFormat = ResponseFormat.Json)]
  12:     public string GetCustomer()
  13:     {
  14:         // Method Body
  15:     }
  16: }

Lines 1-3, I imported 3 additional namespaces to use in the code.  System.Collections.Generics will be used in the next section.  System.Web.Script.Services allow us to decorate the service and it's methods as Script methods for the ScriptHandlerFactory to use when making AJAX calls to and from the client.

Line 7 decorates the web service with the [ScriptService()] attribute.

Line 11 decorates the GetCustomer() web method with the [ScriptMethod()] attribute.  This attribute tells the ScriptHandlerFactory that this method is allowed to be called from an Ajax Client.  The properties inside of the attribute, ResponseFormat = ResponseFormat.Json, tells the ScriptHandlerFactory to send the response stream as a json string and not XML or Soap.  If a response to the web service that is not formatted as json, the response will be returned as XML.

At this point, we can create the body of our web method in any fashion as long as it returns a string.  If you are only passing base types, you can skip down to the Talking to the Server Using jQuery section; however, if you want to pass something a bit more complex, I recommend you continue to the next section.


Using the JavaScriptSerializer and a Custom Converter:

While passing base types is easy enough, it can be important to pass objects back and forth from the client.  In order to assist with this, the ASP.Net AJAX Extensions v1.0 comes with the JavaScriptSerializer object.  This object has the ability to serialize certain objects into strings representing json objects.  This sounds great and the answer to all of our problem!  Too bad it is very limiting in it's natural state.  It CAN convert Arrays of base types and (from what I can tell) any framework classes that implements IEnumerable<T>.  I haven't experimented with some of the more obscure generic collections; however, I do know that it does concern List<T> and Dictionary<S,V> just fine.

In order to use the JavaScriptSerializer, you simply instantiate it and call its Serialize() method, passing the object that you wish to serialize.  If this is a string array or an object of type Dictionary<string,string>, it will do all of the heavy conversion for you and give you a nice little string to return to the client as shown below:

   1: // Method Body
   2: Dictionary<string, string> customerInfo = new Dictionary<string, string>();
   3: customerInfo.Add("FirstName", "John");
   4: customerInfo.Add("LastName", "Doe");
   5: customerInfo.Add("EmailAddress", "JohnDoe@Domain.Com");
   6: customerInfo.Add("PhoneNumber", "555-555-1212");
   8: return new JavaScriptSerializer().Serialize(customerInfo);

In this code snippet, I have instantiated a new Dictionary<string,string> generic object and populated with the property information for a customer.  Lastly, I instantiate a new JavaScriptSerializer object and call it's Serialize method, passing our customer information into it.  The JavaScriptSerializer will create following string from our dictionary:

   1: {"FirstName":"John","LastName":"Doe","EmailAddress":"JohnDoe@Domain.Com","PhoneNumber":"555-555-1212"}

This is just a simple string that, technically, we could have concatenated ourselves; however, you see how it converts the name-value pairs of the Dictionary object and turns them into a json Object with properties and string values.

Seems pretty simple.  Now, let's turn our customer Dictionary into a CustomerInfo object with the same four properties.  Below is the class definition:

   1: public class CustomerInfo
   2: {
   3:     public string FirstName { get; set; }
   4:     public string LastName { get; set; }
   5:     public string EmailAddress { get; set; }
   6:     public string PhoneNumber { get; set;}
   7: }

Now, if we replace our Dictionary object with our CustomerInfo object we get code that looks similar to the following, easier to read, snippet:

   1: // Method body
   2: CustomerInfo custInfo = new CustomerInfo();
   3: custInfo.FirstName = "John";
   4: custInfo.LastName = "Doe";
   5: custInfo.EmailAddress = "JohnDoe@Domain.Com";
   6: custInfo.PhoneNumber = "555-555-1212";
   8: return new JavaScriptSerializer().Serialize(custInfo);

Sadly, running the above code will give you the following error when you attempt to run it:


Since the JavaScriptSerializer doesn't know the definition of our CustomerInfo object, we get this Circular Reference error.  This causes us to go down one of two roads.  We can either turn the object manually back into our Dictionary object, or we can write a custom JavaScriptConverter for our CustomerInfo Class.  The nice thing about a custom converter is that once it's setup to our JavaScriptSerializer, we can then have it convert any number of CustomerInfo classes (or collections of CustomerInfo objects) we may need.


Writing A Custom JavaScriptConverter

Writing our own custom JavaScriptConverter is not as difficult as one may first assume.  Inside the System.Web.Script.Serialization namespace, we are provided with an abstract base class that helps us outline the definition and gets us started quickly.  In our project, let's add another class called CustomerInfoConverter.  Have the class inherit from the JavaScriptConverter class and right-click on the class name and select "Implement Abstract Class".  What you get is the following code snippet:

   1: public class CustomerInfoConverter : JavaScriptConverter
   2: {
   3:     public override object Deserialize(IDictionary<string, object> dictionary, Type type, JavaScriptSerializer serializer)
   4:     {
   5:         throw new Exception("The method or operation is not implemented.");
   6:     }
   8:     public override IDictionary<string, object> Serialize(object obj, JavaScriptSerializer serializer)
   9:     {
  10:         throw new Exception("The method or operation is not implemented.");
  11:     }
  13:     public override IEnumerable<Type> SupportedTypes
  14:     {
  15:         get { throw new Exception("The method or operation is not implemented."); }
  16:     }
  17: }


The first method the JavaScriptConverter makes us define is the Deserialize method.  This method is used by the JavaScriptSerializer to convert a json object from a client into the expected type of the web method uses as a parameter.  The JavaScriptSerializer automatically converts the json object into a Dictionary<string, object> collection.  Inside this method, you could add our mappings between the Dictionary keys to a new CustomerInfo object's properties and finally return that new instance of the CustomerInfo object.  Below is the method body:

   1: CustomerInfo cust = new CustInfo();
   2: cust.FirstName = dictionary["FirstName"].ToString();
   3: cust.LastName = dictionary["LastName"].ToString();
   4: cust.EmailAddress = dictionary["EmailAddress"].ToString();
   5: cust.PhoneNumber = dictionary["PhoneNumber"].ToString();
   7: return cust;


The second method the JavaScriptConverter makes us define is the Serialize method.  This method is used during the actual serialize process.  Here, we're creating a new Dictionary<string, object> collection for our CustomerInfo class.  Since our CustomerInfo class will be boxed through the method's parameter, we'll need to properly cast it before we can start adding the values to the Dictionary object.  Below is the method body:

   1: // Cast the obj parameter
   2: CustomerInfo cust = obj as CustomerInfo;
   4: if (cust != null)
   5: {
   6:     Dictionary<string, object> result = new Dictionary<string, object>();
   7:     result.Add("FirstName", cust.FirstName);
   8:     result.Add("LastName", cust.LastName);
   9:     result.Add("EmailAddress", cust.EmailAddress);
  10:     result.Add("PhoneNumber", cust.PhoneNumber);
  12:     return result;
  13: }
  15: // If the obj doesn't convert for some reason, return an empty dictionary.
  16: return new Dictionary<string, object>();


The last item the JavaScriptConverter makes us define is the SupportedTypes property of type IEnumerable<Type>.  This property should be a collection of types that this converter supports.  Since we are using this converter only for our CustomerInfo class, the property can be simplified to the following line of code:

   1: get { return new Type[] { typeof(CustomerInfo) }; }


Now that we have our converter built, we can attach it to our serializer to get our json string as shown below:

   1: CustomerInfo cust = new CustomerInfo();
   2: cust.FirstName = "John";
   3: cust.LastName = "Doe";
   4: cust.EmailAddress = "";
   5: cust.PhoneNumber = "555-555-1212";
   7: JavaScriptSerializer jss = new JavaScriptSerializer();
   8: jss.RegisterConverters(new CustomerInfoConverter[] { new CustomerInfoConverter() });
   9: return jss.Serialize(cust);


Talking to the Server using jQuery:

Now that we have our server-side infrastructure setup, we can begin to write our AJAX client-side code using jQuery.  Compared to all of the code we've written, this is the easier part.  Below is the JavaScript/jQuery code that can be used to call our web service:

   1: function GetCustomerFromServer()
   2: {
   3:     $.ajax({
   4:         type: "POST",
   5:         url: "/JsonService.asmx/GetCustomer",
   6:         dataType: "json",
   7:         data: "{}",
   8:         contentType: "application/json; charset=utf-8",
   9:         success: function(msg){
  10:             var custInfo = eval("(" + msg + ")");
  11:             alert(custInfo.FirstName);
  12:         }
  13:     });
  14: }

In this client-side code, we're making a HTTP Post call to our web service by calling the web method of it directly.  We are stating that we are sending and receiving data in json format.  Despite the fact that our GetCustomer() web method does not take any parameters, we still need to send an empty json object in order to have json returned.

Lastly, we write an anonymous method to handle the successful message returned to us.  The message is evaluated in order to be turned into a json object on the client side.  We then validate the object by echoing the FirstName property in an alert box.

One thing to remind, this is for ASP.Net 2.0 Web Services.  The response from ASP.Net 3.5 Web Services IS different in that the response message (msg) has it's content in a property only called "d".  So instead of eval("(" + msg + ")"), it would be eval("(" + msg.d + ")").


This post has covered a large amount of steps to get a json-based web service infrastructure setup using jQuery and ASP.Net 2.0 web services.  After a lot of low level research and asking questions to people, I realized that there was not a single location for this information. Hopefully, this post will help fill that gap.
