Wednesday, October 15, 2008

Starting With jQuery - How to Write Custom Validation Rules

This series of posts on using jQuery with no prior knowledge comes to its fifth iteration. Today, I'm going to look more in depth at the Validation Plug-in.  We'll be looking at what rules the Validation Plug-in comes with out of the box followed by an example of how to create your own rules.   In addition to the typical project that I typically supply, I am also including a list of custom Validations that I have used to hopefully make everyone's life a little easier.
If you would like to review the previous posts in this series, please feel free to review the links below:

Required Downloads to use the Examples:

In order to use the Validation plug-in, you'll need to add a few things to your web page:

Code Downloads for this Post:

Source Code Download: Starting With jQuery - Custom Validation Rules.zip
Just the Rules File: Starting With jQuery - Additional Validation Rules.zip

A Look at some of the Built-In Validation Rules:

A wiser man than I once said that you should strive to never be your own plumber in software development.  Ultimately, you shouldn't spend time writing something that has already been written for you by someone else, is accessible, and meets your needs.  To go along with this concept I think it would be best to briefly cover what rules are already built into this excellent plug in.
  • Required: The typical and probably most used validation out there.
  • Minlength & Maxlength: Staple Length validation rules
  • Rangelength: Similar to Min/Maxlength; allows for selected item counts as well.
  • Min & Max & Range: Same as the "length" rules above only for numeric values.
  • Email: A very robust email validation rule
  • Url: Ensures the input is a well formatted url.
  • Date: Verifies the input can be parsed into a date.
  • Number: Ensures that the input is numeric.
  • Digits: Ensures only 0-9 characters (no commas, decimal points, etc.)
  • Credit Cards: Another complex and common validation rule made easy.
  • Accept: A file extension validation rule.
  • EqualTo: Ensures that the values of 2 elements are the same.
This is just a high level list of what's built in.  For additional information on all of the built in rules and how to use them, head over to the plug-in's documentation pages at http://docs.jquery.com/Plugins/Validation#List_of_built-in_Validation_methods.

Creating a Custom Validation Rule:

Now that we know what's already available, there may come a situation where we find that the built in rules just don't cover everything we need.  When such an occurrence comes upon us, we have the ability to extend the Validation Plug-in.  Custom validation rules are, ultimately, methods that are called and return a boolean value; true if the test succeeds and false if the test fails.  After the methods are created, they can be wired up to the jQuery validation component and used like any other rule.
To create a function that will encapsulate our validation test, we need to use one of the following signatures:
function myTest(value, element){...}
//OR
function mytest(value, element, params){...}
These function signatures, are identical except for the last parameter.  The value parameter houses the value that will be tested.  The element represents the element that is being tested.  The params involves any data that is being passed into the test (i.e. a minimum length value).
Looking over the list of built in validation rules, I noticed that one that was missing was a "Text Only" rule to ensure that only alpha characters would appear in the field.  Using this as an example, our validation rule function would look something like this:
function myTextOnlyValidation(value, element){
    return /[a-zA-Z ]/.test(value);
}

After we have the function established, we can then attach it to the jQuery Validation plug-in.  To do this, we call the validator object's addMethod() function.  This addMethod() function takes 3 parameters; a label for the rule, the function that contains the test, and the default message to display when the test fails.
$.validator.addMethod("textOnly", myTextOnlyValidation, "Please enter only alpha characters( a-z ).");
Now that the function has been added, we can use the rule, called "textOnly", just like any of the built in rules.

Putting it all Together:

Now that we've looked at the built in rules, created our own rule, and wired up our custom rule; all that's left is to put everything together.  In this example, we're going to keep things simple and use just a single text box, a label, and a submit button (see Figure 1 below).
jQuery5 - Default Form Image
Figure 1 - the default form
For the example, we'll be applying 2 validation rules to this textbox.  The first will be the same required rule that we applied when we were first introduced to the Validation Plug-in.  The second rule will be our custom textOnly rule.  In order to do such, we need to add the following JavaScript to our code:
   1: //Our validation script will go here.
   2: $(document).ready(function(){
   3:
   4:     //custom validation rule - text only
   5:     $.validator.addMethod("textOnly",
   6:                           function(value, element) {
   7:                               return !/[0-9]*/.test(value);
   8:                           },
   9:                           "Alpha Characters Only."
  10:     );
  11:
  12:     //validation implementation will go here.
  13:     $("#TestForm").validate({
  14:         rules: {
  15:             txtTextOnly: {
  16:                 required: true,
  17:                 textOnly: true
  18:             }
  19:         },
  20:         messages: {
  21:             txtTextOnly: {
  22:                 required: "* Required"
  23:             }
  24:         }
  25:     });
  26: })
Note that in the example, the validation function is anonymous inside of the addMethod() function.
After the JavaScript has been applied to the form, we can verify that it works, as shown in Figure 2.
jQuery5 - Text Only Message
Figure 2 - Validating the Custom Rule

Some Additional Custom Rules:

I used the TextOnly rule in the example because it's a rather simple one to illustrate; however, any number of rules can be applied in the same way.  In order to provide additional content and to hopefully give others a jumpstart on implementing the jQuery Validation Plug-in onto their site, I have also added some additional custom rules.  These additional rules, available with in the example site or as a separate download, provide the following functionality:
  • Phone Numbers (in ###-###-#### format)
  • US Postal Codes ( ##### or #####-#### format)
  • Canadian Postal Codes
In addition, I highly encourage anyone interested in writing their own rules to play around and see what you can come up with.  With the power of jQuery, it's possible to pass 2 elements into test functions as parameters to verify something like a mathematical flash card scenario.  In addition, if you are looking for a good Regular Expression repository, I'd highly recommend http://www.regexlib.com for some additional patterns.



UPDATE 25 September 2012:

Since this is one of my most popular posts (THANK YOU!) I decided to address some comments about the example I wrote 4 years ago not working today.

In terms of the advances of jQuery and the jQuery validation plugin, the code sample will still work properly; however, you'll need to upgrade both of them to the most recent versions (as of this update jQuery 1.8.2 and jQuery Validation 1.9).  Once this is done, the code sample will function continue to function as designed.

There is 1 small bug in the code sample though.  The textOnly rule found in ValidationRules.js and AdditionalRules.js has a bug with the regular expression.  Instead of an asterisk (*) in the regular expression pattern, it should be a plus-sign (+) to signify 1 or more instead of 0 or more.  Correcting this little bug will allow you to use the example rules without an issue.
